LCN 4031HWPAAL HW/PA Hold-Open Door Closer, Aluminum
Parallel Arm Adjustable Surface Mounted Universal Cast Iron Hold Open Door Closer with Thru Bolts 689
Free Shipping Eligible
On orders over $299
LCN 4031HWPAAL HW/PA Hold-Open Door Closer, Aluminum - Aluminum is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
The LCN 4031HWPAAL door closer is a complete 4031 surface-mounted closer with a hold-open arm and parallel-arm bracket in Aluminum (689). The package includes thru bolts.
LCN 4031 configuration and mounting
The HW/PA package offers regular-arm, top-jamb or parallel-arm mounting. Confirm frame clearance and any required mounting plate against the manufacturer template. The mechanical hold-open configuration is for non-fire-rated openings.
Model/SKU: 4031HWPAAL
Series: LCN 4030
Arm package: HW/PA: hold-open arm with parallel-arm bracket.
Finish: Aluminum (689)
Spring power: Adjustable sizes 1–4
Handing: Non-handed
Construction: Cast iron cylinder with metal cover
Grade: ANSI/BHMA A156.4 Grade 1
Fasteners: Thru bolts
Installation instructions and related options
Use the LCN 4031 pull-side and parallel-arm installation instructions or top-jamb installation instructions for the intended mounting. See the manufacturer's 4030 Series specifications and resources for application details.
Compare other 4031 packages: 4031RWPADKBRZ RW/PA Door Closer, Dark Bronze; 4031RWPAAL RW/PA Door Closer, Aluminum; 4031 Regular Arm Door Closer with Thru Bolts.
Browse LCN surface mounted door closers, LCN replacement parts or all LCN door closers. See the LCN manufacturer warranty.
Do not scale printed instructions to mark drilling locations. Follow the dimensions and mounting requirements shown in the manufacturer's instructions.
-
