Kwikset 955KNL Kingston SmartCode Lever Lock with SmartKey

The Kwikset SmartCode 955 Kingston is a light-commercial electronic lever lock designed for high-traffic entry doors that need keypad convenience and keyed backup.

Users can enter with a programmed code or a compatible KW1 key. SmartKey Security allows the keyed cylinder to be re-keyed, and the reversible Kingston lever supports left- or right-hand installation.

Product Details

• Manufacturer part number: 955KNL
• Function: Light Commercial Electronic Keypad Lever Lock
• Access: Keypad code or KW1 SmartKey keyed backup
• User codes: Up to 30
• ANSI/BHMA grade: Grade 2
• UL fire rating: 20 minutes
• Handing: Reversible
• ADA compliant: Yes
• Backset: Adjustable
• Door thickness: 1-3/8″ to 2″
• Cross bore: 2-1/8″
• Power: One included 9V battery
• Keys: Two

Included and compatibility: Includes the electronic lever lock, two keys and a 9V battery. Confirm the latch, strike, door preparation and programming requirements for the selected SKU.

View Kwikset Manufacturer Warranty
Shop All Kwikset Products

Review the dimensions, door preparation and exact SKU requirements before ordering. Manufacturer documents may not print at exact scale.
