Copper Creek ZL2240 Zane Single Cylinder Keyed Entry Door Lever

The Copper Creek ZL2240 Zane is a Grade 3 residential keyed entry door lever with a contemporary lever and square rose.

The exterior key or inside turn-button locks both levers. The complete lockset operates a spring latch and provides keyed access from outside with normal lever operation from inside.

Product Details

• Model: ZL2240
• Design: Zane
• Function: Residential Keyed Entry Door Lever
• Lever style: contemporary
• Rose: 2-5/8″ square rose
• Lever length: 4-3/4″
• Configuration: interior and exterior levers, cylinder, adjustable latch, strike and mounting hardware
• Material: zinc
• Performance: ANSI/BHMA Grade 3; 200,000 cycles
• Door thickness: 1-3/8″ to 1-3/4″
• Backset: adjustable 2-3/8″ or 2-3/4″
• Cross bore: 2-1/8″
• Edge bore: 1″
• Handing: non-handed / reversible
• Standard latch faceplate: 1″ round corner
• Standard strike: 2-3/4″ full-lip round-corner strike
• Cylinder: solid-brass 5-pin KW1 standard; C keyway optional

Compatibility: Confirm the ZL2240 Zane design, square rose, keyed-entry function, door thickness, backset, latch and strike preparation, keyway, and keying before ordering. This is a lever lockset, not a lever-and-deadbolt combination.
